Matrica HDMI Blustream CMX88AB

Šifra proizvoda: 39192, stanje skladišta: na upit
CMX88AB 4K HDMI Matrix offers unprecedented performance and value for the custom installation market. The CMX88AB supports HDMI2.0 with HDCP2.2, allowing distribution of eight HDMI sources to eight displays. This enables all sources to be viewed as required within a matrix configuration. The unit transmits all HDMI resolutions up to and including 4K 60Hz 4:4:4. The 8-Way matrix also includes audio breakout, EDID management and a web browser interface module for control and configuration of the matrix.

  • Features 8x HDMI inputs which can be independently routed to 8x HDMI outputs

  • Supports HDMI2.0 18Gbps specification including HDR

  • Supports up to 4K UHD 60Hz 4:4:4

  • Independent video down conversion on all HDMI outputs allowing for displays only capable of supporting lower 4K video resolutions (4K 60Hz 4:2:0) to receive native 4K 60Hz 4:4:4 video content while still showing maximum original 4K UHD resolution on remaining video outputs

  • Supports all industry standard video resolutions including VGA-WUXGA and 480i-4K

  • Supports all known digital HDMI audio formats including Dolby TrueHD, Atmos; DTS-HD Master Audio and DTS:X transmissions

  • HDMI audio breakout to associated output analogue L/R audio and coaxial digital outputs concurrently

  • Web interface module for control and configuration of Matrix

  • Control via front panel, IR, RS-232 and TCP/IP

  • 3rd Party drivers available for all major home control brands

  • Advanced EDID management

  • HDCP2.2 compliant



 Proizvođač Blustream
 Tip Matrični preklopnik
 Ulazi 8x HDMI, 8x IR
 Izlazi 8x HDMI, 8x Audio, 8x IR
 Propusnost 18 Gbps (HDR)
 Podržani signali do 4K UHD (60Hz 4:4:4)
 Kontrola RS232, RS485, RJ45, EDID, TCP/IP
 Snaga -
 Napajanje 12V/3A DC
 Dimenzije                            441x45x226 mm
 Težina 3 Kg
 Jamstvo 2 godine
Redovna cijena
Cijena bez PDV: na upit
Cijena sa PDV: na upit
