Matrični preklopnik Aten VM1600A

Šifra proizvoda: 39454, stanje skladišta: na upit
  1. Povezuje 16 video uređaja sa 16 zaslona/monitora
  2. 4k matrični preklopnik bez zadrške (seamless switch)
  3. Funkcija video zida

Connects any of 16 video sources to any of 16 displays in combination with ATEN Modular Matrix I/O Boards
Multiple means for system configuration including front-panel pushbuttons, RS-232/422/485 control, and Ethernet connections for web GUI or Telnet
4K resolutions –up to UHD (3840 x 2160) and DCI (4096 x 2160) with refresh rates of 30 Hz (4:4:4) and 60 Hz (4:2:0)*
Scaler –features a (4K) video scaling function to convert input resolutions to the display’s native resolutions*
Seamless Switch™ –features close-to-zero second switching for continuous video streams, real-time switching, and stable signal transmissions*
Video wall –allows you to create custom video wall layouts via intuitive web GUI*
Calendar-based scheduling – allows profile playing based on the pre-set schedule and RTC
EDID Expert –selects optimum EDID settings for smooth power-up, high-quality display, and use of the best resolutions across different screens
Audio-enabled –HDMI audio can be extracted and stereo audio can be embedded*
Bi-directional RS-232 channel – allows you to control the connected serial devices simultaneously through the web GUI
Supports redundant power module for higher reliability
Hot-swappable design for I/O boards, fan module, and power supplies for easy maintenance and higher reliability
Optional redundant power supply –ensures reliability for mission-critical applications
Long-Reach mode up to 1080p@150m – enables extended AV transmission using the HDBaseT™ Input/Output board with ATEN HDBaseT™ Class A Video Extenders
HDCP 2.2 Compatible*
HDMI: 3D, Deep Color, 4K*
Consumer Electronics Control (CEC) supported*
Rack mountable (6U design)


 Proizvođač Aten
 Tip Matrični modularni preklopnik
 Ulazi max 16 ulaza (4x utor za ulaznu ploču)
 Izlazi max 16 izlaza (4x utor za izlaznu ploču)
 Propusnost 15.2 Gbps (3.8Gbps per Lane)
 Podržani signali do 4K, UHD (3840 x 2160), DCI (4096 x 2160) 30 Hz (4:4:4) i 60 Hz (4:2:0)
 Kontrola EDID, IR, RS232, WEB-GUI
 Snaga -
 Napajanje 100-240 VAC; 50/60Hz; 3/6 A
 Dimenzije                            482x266x466 mm
 Težina 11,5 Kg
 Jamstvo 3 godine
