Extends HDMI and IR signal over one CAT5/5e/6 cable.
Uncompressed high definition video up to 1080p@60Hz@48bits and 3D and 4K*2K capable.
Bi-directional IR, support 30-60kHz.
Max. Data Rate- 10.2Gbps.
HDMI 1.4 and HDCP compliance.
Transmission range up to 70M by CAT5e/6 at 1080p@60Hz@24bit.
Audio support up to LPCM7.1, Dolby TrueHD, DTS-HD MA.
Support PoH (Power over HDBaseT), no external power required at receiver.
External power supply included for the Transmitter.
| Proizvođač |
SC&T |
|
| Tip |
twisted pair |
|
| Ulazi |
1xRJ45, 1xHDMI, 1xIR |
|
| Izlazi |
1xRJ45, 1xHDMI, 1xIR |
|
| Propusnost |
10.2 Gbs |
|
| Podržani signali |
do 4Kx2K, FullHD (1920x1080), 3D |
|
| Kontrola |
- |
|
| Snaga |
- |
|
| Napajanje |
12V-DC, 500mA predajnik, POH prijemnik |
|
| Dimenzije |
67x95x27 mm |
|
| Težina |
0,15 Kg |
|
| Jamstvo |
12 mjeseci |
|
|
|
|
