Connects any of 8 HDMI sources to any of 8 HDMI displays
Supports True 4K resolutions up to 4096 x 2160 @ 60Hz (4:4:4)
Supports HDR10+
Multiple Control Methods – system management via front-panel pushbuttons, IR remote, RS-232 control, and Web GUI/Telnet via Ethernet connections
EDID Expert™ – selects optimum EDID settings for smooth power-up, high-quality display and use of the best video resolution across different screens
Signaling rates up to 6 Gbits for flawless true 4K output
Supports Dolby True HD and DTS HD Master audio
HDMI (3D, Deep Color, 4K) and HDCP 2.2 compatible
Supports Consumer Electronics Control (CEC)
Power-on Detection – switches to the next powered-on source when one source is powered off
ESD protection for HDMI
Supports ATEN’s LockPro™ HDMI cable lock for secure HDMI cable connections
Firmware upgradeable
Rack mountable (1U design)
| Proizvođač |
Aten |
|
| Tip |
Matrični HDMI preklopnik |
|
| Ulazi |
8x HDMI, 1x RS232, 1x audio stereo, 1x RJ-45 Female |
|
| Izlazi |
8x HDMI |
|
| Propusnost |
18 Gbps( 6 Gbps Per Lane) |
|
| Podržani signali |
do 4K, 4096 x 2160 / 3840 x 2160 @ 60Hz (4:4:4) |
|
| Kontrola |
tipke, RS232, IR, EDID, Web GUI/Telnet |
|
| Snaga |
-
|
|
| Napajanje |
100-240 VAC |
|
| Dimenzije |
262,3x44x432,4 mm |
|
| Težina |
3,99 Kg |
|
| Jamstvo |
2 godine |
|
|
|
|
