Extends HDMI, RS-232, and IR signals up to 100 m over a single Cat 5e/6/6a
Superior video quality: 4K up to 100 m / 1080p up to 150 m
HDBaseT Long Reach Mode – activated by RS-232 commands, Long Reach Mode extends signals up to 150 m, 1080p, via a single Cat 5e/6 cable
Scaler – scales videos of different resolutions to their optimal output for display and to avoid black screen*
Video Wall – features video wall profiles that allows for custom screen layouts via an intuitive web GUI**
Seamless Switch™ – close-to-zero second switching that provides continuous video streams, real-time switching, and stable signal transmissions**
HDBaseT Anti-jamming – resists signal interference during high-quality video transmissions using HDBaseT technology
Bi-directional RS-232 channel – allows for control using serial terminals or serial devices, such as touch screens and barcode scanners
Bi-directional IR channel – IR transmission is processed one direction at a time***
Cable Quality Tester – examines the category cable quality through signal level detection from HDBaseT Matrix Switches to the VE816R.
FrameSync – prevents image tearing by synchronizing the scaler output frame rate to the input signal frame rate
Built- in 8KV / 15 KV ESD protection
Plug-and-play
Rack-mountable
| Proizvođač |
Aten |
|
| Tip |
HDBaseT prijemnik |
|
| Ulazi |
1x RJ-45 Female, 1x audio stereo, 1x Terminal Block |
|
| Izlazi |
1x HDMI Type A Female |
|
| Propusnost |
10.2 Gbps (3.40 Gbps per lane) |
|
| Podržani signali |
do 4K@70m (Cat 5e/6) / 100m (Cat 6a/ATEN 2L-2910 Cat6); 1080p@100m (Cat 5e/6/6a) |
|
| Kontrola |
IR, RS232 |
|
| Snaga |
-
|
|
| Napajanje |
-
|
|
| Dimenzije |
146,9x30x168 mm |
|
| Težina |
0,67 Kg |
|
| Jamstvo |
2 godine |
|
|
|
|
