Displays the video output of four computers on a single monitor or projector
Quick and easy switching between VGA/Audio sources via front panel pushbuttons, RS-232, or IR remote control
Superior video quality – up to 1920 x 1440
Long-distance transmission – up to 30 m *
Supports VGA, SVGA, UXGA, WUXGA and multisync monitors
Video DynaSync™ – Exclusive ATEN technology eliminates boot-up display problems and optimizes resolution when switching between ports
Built-in bi-directional RS-232 serial port for high-end system control **
RS-232 Control:
• Power On Detection – if one VGA source is powered off, the VS0401 will automatically switch to the next powered-on
source
• Auto Switching – sets the priority for auto switching to a connected port
• Pushbutton Lock – locks use of the front panel pushbuttons
Supports stereo audio
DDC compatible
Supports up to 300MHz bandwidth for optimal video quality
LED indication of power status and source device
All-metal casing provides durability and protection
Plug-and-play – no software installation required
| Proizvođač |
Aten |
|
| Tip |
Preklopnik |
|
| Ulazi |
4x VGA, 4x Audio stereo |
|
| Izlazi |
1x VGA, 1x Audio stereo |
|
| Propusnost |
- |
|
| Podržani signali |
do 1920 x 1440 @ 60Hz |
|
| Kontrola |
tipke, EDID, RS232, IR (opcija) |
|
| Snaga |
- |
|
| Napajanje |
5,3V / 1A DC |
|
| Dimenzije |
200x76x44 mm |
|
| Težina |
0,66 Kg |
|
| Jamstvo |
2 godine |
|
|
|
|
